Description

A ship is a man-made vehicle that operates primarily on geographical waters. Civilian ships are generally called ships, military ships are called warships, and small ships are called boats or boats. They are collectively called ships or boats. The interior mainly includes accommodation space, support structure and drainage structure, and has a propulsion system that utilizes external or self-generated energy. The appearance is generally a streamlined envelope that is conducive to overcoming fluid resistance. The materials are constantly updated with the advancement of science and technology. In the early days, they were natural materials such as wood, bamboo, and hemp. In modern times, they are mostly steel, aluminum, fiberglass, acrylic, and various composite materials.

The main problems solved in this plan:

During the operation of the ship, in order to avoid the possibility of the ship tilting and rolling over, threatening the safety of personnel.

Solution

HWT905 tilt sensor, high precision and high stability. The inclination sensor is generally installed on the horizontal platform of the ship deck. The inclination sensor is used to monitor the level of the ship for a long time. Once the inclination exceeds the safe value, an alarm signal will prompt and notify personnel to perform inspection and maintenance. If necessary, corresponding measures should be taken. protective measures to ensure the safe navigation of ships. The inclination sensors (HWT905, HWT605) produced by our company can effectively get rid of this problem. This ensures that the ship is always in a horizontal state to ensure the safe operation of the ship.

Parameter:

Product name: HWT905

Chip solution: military grade

Power supply voltage: 9~36V

Working current: <40mA

Communication method: serial port TTL, serial port 232, Serial port 485 (Modbus protocol), CAN

Output data: three-dimensional (acceleration, gyroscope, Euler angle, magnetic field) quaternion, time

Measuring range: Acceleration: ±6g Gyroscope: ±2000°/s Angle: X, Z±180°, Y±90°

Angle accuracy: X, Y axis static 0.05° dynamic 0.1° Z axis: 1° (no magnetic field interference and calibrated)

Magnetic field accuracy: 1mg (milligauss)

Return rate: 0.2~200Hz (adjustable)

Baud rate: 4800~921600

Size: 55*36.8*24mm, default line length is 1 meter

Installation method: vertical or horizontal optional, horizontal installation by default
