    Current type tilt switch

    buy now

    Overview

    1. The module integrates high-precision gyroscope and accelerometer. Using a high-performance microprocessor and advanced dynamics solution and Kalman dynamic filtering algorithm, it can accurately output the current attitude of the module in a dynamic environment. The attitude measurement accuracy is statically 0.1°, the stability is extremely high, and the performance is even better than some Some professional inclinometers.

    2. The SIN-IT series is a small-sized, low-cost dual-axis current output inclination sensor with an output current of 4~20mA, 0~20mA, 0~24mA, 5~25mA. It has a built-in high-precision tilt unit and low power consumption. It is a high-precision tilt switch. Two analog current outputs for X axis and Y axis, angle range ±5°, ±10°, ±15°, ±30°, ±60, ±90. Real-time monitoring on the host computer.

    3. Support serial digital interface. It is convenient for users to choose the best connection method. The serial port rate is adjustable from 4800bps to 230400bps.

    4. The module has its own voltage stabilization circuit, and the working voltage is 12V~36V and is easy to connect.

    5. Maximum data output rate of 200Hz. The output content can be selected arbitrarily, and the output rate is adjustable from 0.2 to 200Hz.


    Specifications

    Accelerometer parameters

    Parameters

    Condition

    Typical value

    Measuring range


    ±16g

    Resolution ratio

    ±16g

    0.0005(g/LSB)

    RMS noise

    Bandwidth=100Hz

    0.75~1mg-rms

    Static zero drift

    Place horizontally

    ±20~40mg

    Temperature drift

    -40°C ~ +85°C

    ±0.15mg/℃

    Bandwidth


    5~256Hz

    Gyroscope parameters

    Parameters

    Condition

    Typical value

    Measuring range


    ±2000°/s

    Resolution ratio

    ±2000°/s

    0.061(°/s)/(LSB)

    RMS noise

    Bandwidth=100Hz

    0.028~0.07(°/s)-rms

    Static zero drift

    Place horizontally

    ±0.5~1°/s

    Temperature drift

    -40°C ~ +85°C

    ±0.005~0.015 (°/s)/℃

    Bandwidth


    5~256Hz



    Pitch and roll angle parameters

    parameters

    Condition

    Typical value

    Measuring range


    XY:±90°

    Inclination accuracy

    		Static

    0.1°

    Inclination accuracyDynamic0.5°

    Resolution ratio

    Place horizontally

    0.0055°

    Temperature drift

    -40°C ~ +85°C

    ±0.5~1°

    Heading angle parameter

    Parameters

    Condition

    Typical value

    Measuring range


    Z:±180°

    Heading accuracy

    6-axis algorithm, static

    0.5°（Dynamic integral cumulative error exists）[1]

    Resolution ratio

    Place horizontally

    0.0055°

    Note: [1] In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and will be subject to actual testing.
