Overview
1. This product is a high-performance two-axis motion attitude measurement system based on MEMS technology. It contains a three-axis gyroscope, a three-axis accelerometer, and a motion sensor. By integrating various high-performance sensors and using the independently developed attitude dynamics core algorithm engine, combined with the high-dynamic Kalman filter fusion algorithm, the MEMS high-precision module can directly output the inclination angle.
2. The leading sensor fusion algorithm based on the Kalman filtering principle and with independent intellectual property rights can provide data with an update rate of up to 200Hz in real time, thereby meeting various high-precision application requirements and achieving accurate motion capture and attitude estimation.
3. It has the country's leading high-precision turntable equipment and instruments, and the products integrate self-developed high-precision calibration and calibration algorithms to improve the measurement accuracy of the products.
4. The SIN series products are inclination sensors developed and produced by Shenzhen Weite Intelligent Technology Co., Ltd., with a built-in high-precision inclination measurement unit. By measuring the static gravity acceleration, it is converted into inclination changes, so that the inclination and pitch angle of the sensor output relative to the horizontal plane can be measured. . The output mode is RS232, RS485 or TTL level interface standard optional. This product has high precision. It has good stability and is easy to use, and is widely used in industrial inclination measurement. It is an ideal choice for industrial automation control and platform attitude measurement. It has strong resistance to external electromagnetic interference and can adapt to long-term work in harsh industrial environments.
5. At the same time, we provide various host computers, operating instructions, development manuals, and development codes that users need to minimize the research and development time for various needs.
Specifications
Accelerometer parameters
Parameter | Condition | Typical value |
Range | ±16g | |
Resolution | ±16g | 0.0005(g/LSB) |
RMS noise | Bandwidth=100Hz | 0.75~1mg-rms |
Static drift zero | Placed horizontally | ±20~40mg |
Temperature drift | -40°C ~ +85°C | ±0.15mg/℃ |
Bandwidth | 5~256Hz |
Gyroscope parameters
Parameter | Condition | Typical value |
Range | ±2000°/s | |
Resolution | ±2000°/s | 0.061(°/s)/(LSB) |
RMS noise | Bandwidth=100Hz | 0.028~0.07(°/s)-rms |
Static drift zero | Placed horizontally | ±0.5~1°/s |
Temperature drift | -40°C ~ +85°C | ±0.005~0.015 (°/s)/℃ |
Bandwidth | 5~256Hz |
Pitch and roll angle parameters
Parameter | Condition | Typical value |
Range | XY:±90° | |
Lnclination accuracy | Static | 0.1° |
Dynamic | 0.5° | |
Resolution | Placed horizontally | 0.0055° |
Temperature drift | -40°C ~ +85°C | ±0.5~1° |
Heading angle parameter
Parameter | Condition | Typical value |
Range | Z:±180° | |
6-axis algorithm, static | 0.5° (Dynamic integral cumulative error exists) | |
Resolution | Placed horizontally | 0.0055° |
Note:
【1】In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and are subject to actual testing.
Basic parameters
Parameter | Condition | Minimum | Typical value | Maximum |
Communication Interface | UART | 4800bps | 9600bps | 230400bps |
Start Time | 1000ms | |||
Output content | On-chip time, 3-axis acceleration, 3-axis angular velocity, 3-axis angle | |||
Output rate【1】 | 0.2Hz | 10Hz | 200Hz | |
Operating temperature | -40℃ | 85℃ | ||
Storage temperature | -40℃ | 100℃ | ||
Shock proof | 20000g | |||
Degree of protection | IP67 |
Note:
【1】The 485 product adopts Modbus protocol and is in master-slave mode, which is determined by the user’s read content quantity and reading rate.
Electrical parameters
Parameter | Condition | Minimum | Typical value | Maximum |
Supply voltage | 5V | 12V | 36V | |
Working current | Work(12V) | 14.3mA(TTL) 11.5mA(232) 6.3mA(485) |
Application
· Virtual reality/augmented reality, head-mounted displays
· Large-scale agricultural automatic farming
· Safety monitoring of high-altitude operations
· Drones, manned aircraft
·Industrial attitude monitoring
·Human motion tracking/capture
· Robots, autonomous guided transport vehicles
· Pedestrian navigation
· Unmanned driving/assisted driving
·Military, intelligent weapons and equipment
