  • Overview

    1. A high-performance three-dimensional motion attitude measurement system based on MEMS technology, including a three-axis gyroscope, a three-axis accelerometer, and a three-axis electronic compass, providing high-precision, high-dynamic, and real-time compensated three-axis attitude angles with a wide measurement range range, excellent noise immunity, no hysteresis, and stable temperature characteristics.

    2. Kalman filtering combined with a sensor fusion algorithm with independent intellectual property rights can provide data with an update rate of up to 200Hz in real time to achieve accurate motion capture and attitude estimation.

    3. It has the country's leading high-precision turntable equipment and instruments, and the products integrate self-developed high-precision calibration and calibration algorithms to improve the measurement accuracy of the products.

    4. Provides high-precision, high-dynamic, real-time compensated three-axis attitude angle, which can work stably for a long time in various harsh industrial environments.

    5. At the same time, we provide various host computers, operating instructions, development manuals, and development codes that users need to minimize the research and development time for various needs.

    6. Flexible selection and configuration of various types of data can be used to meet various application scenarios.

    7. It can accurately output the current attitude of the module in a dynamic environment. The attitude measurement accuracy is statically 0.05°, the stability is extremely high, and the performance is even better than some professional inclinometers.


    Specifications

    Accelerometer parameters

    Parameters

    Condition

    Typical value

    Measuring range


    ±6g

    Resolution ratio

    ±6g

    0.00075(g/LSB)

    RMS noise

    Bandwidth=100Hz

    1.2mg-rms

    Static zero drift

    Place horizontally

    ±20mg

    Temperature drift

    -40°C   ~ +125 °C

    ±0.09mg/℃

    Bandwidth


    5~256Hz

    Gyroscope parameters

    Parameters

    Condition

    Typical value

    Measuring range


    ±2000°/s

    Resolution ratio

    ±2000°/s

    0.061(°/s)/(LSB)

    RMS noise

    Bandwidth=100Hz

    0.028~0.07(°/s)-rms

    Static zero drift

    Place horizontally

    ±0.5~1°/s

    Temperature drift

    -40°C   ~ +85°C

    ±0.005~0.015   (°/s)/℃

    Bandwidth


    5~256Hz

    Magnetometer parameters


    Parameters

    Condition

    Typical value

    Measuring range

    loop count value(200)

    -800uT   to +800 uT

    linearity ±200uT

    loop count value(200)

    0.6%

    Resolution ratio

    loop count value(200)

    13nT/LSB

    Pitch and roll angle parameters

    Parameters

    Condition

    Typical value

    Measuring range


    X:±180°

    Y:±90°

    Inclination accuracy


    0.05°

    Resolution ratio

    Place horizontally

    0.0055°

    Temperature drift

    -40°C ~ +85°C

    ±0.5~1°

    Heading angle parameter

    Parameters

    Condition

    Typical value

    Measuring range


    Z:±180°

    Heading accuracy

    9-axis algorithm, magnetic field calibration, dynamic/static

    1°(Without interference from magnetic fields)【1】

    6-axis algorithm, static

    0.5°(Dynamic integral cumulative error exists)

    【2】

    Resolution ratio

    Place horizontally

    0.0055°


    Note:【1】Please perform magnetic field calibration in the testing environment before use to ensure that the sensor is familiar with the magnetic field in the environment. During calibration, please stay away from magnetic interference.

    【2】In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and are subject to actual testing.


    Application

    · Virtual reality/augmented reality, head-mounted displays

    · Large-scale agricultural automatic farming

    · Safety monitoring of high-altitude operations

    · Drones, manned aircraft

    ·Industrial attitude monitoring

    ·Human motion tracking/capture

    · Robots, autonomous guided transport vehicles

    · Pedestrian navigation

    · Unmanned driving/assisted driving

    ·Military, intelligent weapons and equipment
