Overview

1. The module integrates high-precision gyroscopes, accelerometers, and geomagnetic field sensors. It uses high-performance microprocessors and advanced dynamic calculation and Kalman dynamic filtering algorithms to quickly solve the current real-time motion posture of the module. It has It has the advantages of wide measurement range, excellent noise immunity, no hysteresis, and stable temperature characteristics.

2. The use of advanced digital filtering technology can effectively reduce measurement noise and improve measurement accuracy.

3. The product integrates an attitude solver and cooperates with the dynamic Kalman filter algorithm to accurately output the current attitude of the module in a dynamic environment. The attitude measurement accuracy is statically 0.001°, the stability is extremely high, and the performance is even better than some professional ones. Inclinometer.

4. The Z-axis heading angle is added to the geomagnetic sensor filter fusion, which solves the cumulative error caused by the drift of the gyroscope integral in the 6-axis algorithm, and can output heading angle data stably for a long time. (Note: Due to magnetic field detection, calibration is required before use, and when used, it needs to be at least 20cm away from magnetic interference areas, electronic equipment, magnets, speakers and other hard magnetic objects.)

5. The product has its own voltage stabilization circuit, working voltage is 5~36V, and is easy to connect.

6. Military-grade magnetic field chip, automatically recovers from magnetic field interference.

7. P67 level protection, aluminum shell, strong resistance to external electromagnetic interference, stable performance, and can adapt to long-term work in harsh industrial environments.

Specifications

Accelerometer parameters

Parameters	Condition	Typical value
Measuring range		±2g
Resolution ratio	±2g	0.0000039(g/LSB)
Static zero drift	Place horizontally	±25mg
Temperature drift	-40°C ~ +125°C	±0.1mg/℃
Bandwidth		5~256Hz

Gyroscope parameters

Parameters	Condition	Typical value
Measuring range		±2000°/s
Resolution ratio	±2000°/s	0.061(°/s)/(LSB)
RMS noise	Bandwidth=100Hz	0.028~0.07(°/s)-rms
Static zero drift	Place horizontally	±0.5~1°/s
Temperature drift	-40°C ~ +85°C	±0.005~0.015 (°/s)/℃
Bandwidth		5~256Hz

Magnetometer parameters

Parameters	Condition	Typical value
Measuring range	Loop count value (200)	-800uT to +800 uT
Linearity ±200uT	Loop count value (200)	0.6%
Resolution ratio	Loop count value (200)	13nT/LSB

Pitch and roll angle parameters

Parameters	Condition	Typical value
Measuring range		X:±180°
Measuring range		Y:±90°
Inclination accuracy		0.001°
Resolution ratio	Place horizontally	0.001°
Temperature drift	-40°C ~ +85°C	±0.5~1°

Heading angle parameter

Parameters	Condition	Typical value
Measuring range		Z:±180°
Heading accuracy	9-axis algorithm, magnetic field calibration, dynamic/static	1°（Without interference from magnetic fields）【1】
Heading accuracy	6-axis algorithm, static	0.5°（Dynamic integral cumulative error exists）【2】
Resolution ratio	Place horizontally	0.0055°

Note:【1】Please perform magnetic field calibration in the testing environment before use to ensure that the sensor is familiar with the magnetic field in the environment. During calibration, please stay away from magnetic interference.

【2】In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and are subject to actual testing.

Application

telescope wind power bridge Grid transmission tower
