Overview
1. The module integrates high-precision gyroscopes, accelerometers, and geomagnetic field sensors, and uses high-performance microprocessors and advanced dynamic calculations and Kalman dynamic filtering algorithms to quickly solve the current real-time motion posture of the module.
2. The module integrates an attitude solver and cooperates with the dynamic Kalman filter algorithm to effectively reduce measurement noise and improve measurement accuracy. It can accurately output the current attitude of the module in a dynamic environment, with an attitude measurement accuracy of 0.2° and extremely high stability, even better than some professional inclinometers.
3. The output content can be selected arbitrarily, and the data output frequency is 100HZ by default.
4. Four expansion ports are reserved, which can be configured as analog input, digital input, digital output and other functions.
5. Using stamp hole gold plating technology, it can be embedded in the user's PCB board. 4-layer PCB board technology is thinner, smaller, and more reliable.
6. Bluetooth 2.0: supports Android/IOS operating system (actual use is subject to the final device)
Specifications
Parameters | Condition | Typical value |
Measuring range | ±16g | |
Resolution ratio | ±16g | 0.0005(g/LSB) |
RMS noise | Bandwidth=100Hz | 0.75~1mg-rms |
Static zero drift | Place horizontally | ±20~40mg |
Temperature drift | -40°C ~ +85°C | ±0.15mg/℃ |
Bandwidth | 5~256Hz |
Parameters | Condition | Typical value |
Measuring range | ±2000°/s | |
Resolution ratio | ±2000°/s | 0.061(°/s)/(LSB) |
RMS noise | Bandwidth=100Hz | 0.028~0.07(°/s)-rms |
Static zero drift | Place horizontally | ±0.5~1°/s |
Temperature drift | -40°C ~ +85°C | ±0.005~0.015 (°/s)/℃ |
Bandwidth | 5~256Hz |
parameters | Condition | Typical value |
Measuring range | X:±180° | |
Y:±90° | ||
Inclination accuracy | 0.2° | |
Resolution ratio | Place horizontally | 0.0055° |
Temperature drift | -40°C ~ +85°C | ±0.5~1° |
parameters | Condition | Typical value |
Measuring range | Z:±180° | |
Heading accuracy | 6-axis algorithm, static | 0.5°(Dynamic integral cumulative error exists) 【1】 |
Resolution ratio | Place horizontally | 0.0055° |
【1】In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and are subject to actual testing.
Parameter | Condition | minimum value | Default | maximum value |
Communication Interface | UART | 115200bps | 115200bps | 115200bps |
Output content | Three-axis acceleration, three-axis angular velocity, three-axis angle | |||
Output rate | 100Hz | 100Hz | 100Hz | |
Start Time | 1000ms | |||
Number of cascades | Bluetooth multi-link adapter | 4pcs | ||
Bluetooth transmission distance | open environment | 10m | ||
Operating temperature | -20℃ | 60℃ | ||
Storage temperature | -40℃ | 85℃ | ||
Shock proof | 20000g |
Application
· Virtual reality/augmented reality, head-mounted displays
· Large-scale agricultural automatic farming
· Safety monitoring of high-altitude operations
· Drones, manned aircraft
· Industrial attitude monitoring
· Human motion tracking/capture
· Robots, autonomous guided transport vehicles
· Pedestrian navigation
· Unmanned driving/assisted driving
· Military, intelligent weapons and equipment
