Overview

1. The module integrates high-precision gyroscopes, accelerometers, and geomagnetic field sensors, and uses high-performance microprocessors and advanced dynamics calculation and Kalman dynamic filtering algorithms to quickly solve the current real-time motion posture of the module.

2. The module integrates an attitude solver and cooperates with the dynamic Kalman filter algorithm to effectively reduce measurement noise and improve measurement accuracy. It can accurately output the current attitude of the module in a dynamic environment, with an attitude measurement accuracy of 0.2°, extremely high stability, and even better performance than some professional inclinometers.

3. The Z-axis heading angle is added to the geomagnetic sensor filter fusion, which solves the cumulative error caused by the drift of the gyroscope integral in the 6-axis algorithm, and can output heading angle data stably for a long time.

4. The output content can be selected arbitrarily, the data output frequency is 200Hz, and the default is 10HZ.

5. Reserve 4 expansion ports, which can be configured as analog input, digital input, digital output and other functions.

6. Using stamp hole gold plating technology, it can be embedded in the user's PCB board. The 4-layer PCB board technology is thinner, smaller and more reliable.

7. Bluetooth 5.0: supports Android/IOS operating system (actual use depends on the final device)

Specifications

Accelerometer parameters

Parameters	Condition	Typical value
Measuring range		±16g
Resolution ratio	±16g	0.0005(g/LSB)
RMS noise	Bandwidth=100Hz	0.75~1mg-rms
Static zero drift	Place horizontally	±20~40mg
Temperature drift	-40°C ~ +85°C	±0.15mg/℃
Bandwidth		5~256Hz

Gyroscope parameters

Parameters	Condition	Typical value
Measuring range		±2000°/s
Resolution ratio	±2000°/s	0.061(°/s)/(LSB)
RMS noise	Bandwidth=100Hz	0.028~0.07(°/s)-rms
Static zero drift	Place horizontally	±0.5~1°/s
Temperature drift	-40°C ~ +85°C	±0.005~0.015 (°/s)/℃
Bandwidth		5~256Hz

Magnetometer parameters

parameters	Condition	Typical value
Measuring range		±2Gauss
Resolution ratio	±2Gauss	0.0667mGauss/LSB

Pitch and roll angle parameters

parameters	Condition	Typical value
Measuring range		X:±180°
Measuring range		Y:±90°
Inclination accuracy		0.2°
Resolution ratio	Place horizontally	0.0055°
Temperature drift	-40°C ~ +85°C	±0.5~1°

Heading angle parameter

parameters	Condition	Typical value
Measuring range		Z:±180°
heading accuracy	9-axis algorithm, magnetic field calibration, dynamic/static	1°（Without interference from magnetic fields）【1】
heading accuracy	6-axis algorithm, static	0.5°（Dynamic integral cumulative error exists）【2】
Resolution ratio	Place horizontally	0.0055°

Module parameters

Parameter	Condition	minimum value	Default	maximum value
Communication Interface	UART	115200bps	115200bps	115200bps
Output content		3-axis acceleration, 3-axis angular velocity, 3-axis magnetic field, 3-axis angle, quaternion, port status
Output rate		0.2Hz	10Hz	200Hz
Start Time				1000ms
Number of cascades	Bluetooth multi-link adapter			4pcs
Bluetooth transmission distance	open environment			50m
Operating temperature		-20℃		60℃
Storage temperature		-40℃		85℃
Shock proof				20000g

Note:【1】Please perform magnetic field calibration in the testing environment before use to ensure that the sensor is familiar with the magnetic field in the environment. During calibration, please stay away from magnetic interference.

【2】In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and are subject to actual testing.
