Overview

1. The module integrates a high-precision accelerometer, uses a high-performance microprocessor and advanced dynamics calculation and Kalman dynamic filtering algorithms to quickly solve the current real-time motion posture of the module.

2. The product comes with an angle alarm function. Users can set the alarm value by themselves. When the alarm value is exceeded, the sensor reports data. Tilt alarm, remote control via mobile phone WeChat, fast response and stable monitoring. View pictures on mobile phone

3. Using advanced digital filtering technology, it can effectively reduce measurement noise and improve measurement accuracy.

4. LTE full network communication, the remote terminal can view data in real time, control the module, and realize the Internet of Things. Fast network access, low latency, and 4G bearer.

5. Based on the existing operator network, it has wide coverage and high stability. The antenna uses π-type network impedance matching, the standing wave ratio is lower than 1.65, and the signal is stable.

6. Low power consumption mode supports long-term outdoor measurements. The long-lasting standby uses an HPC IoT battery with a battery capacity of 8500mAH, a standby power consumption of less than 10UA, and a standby time of 5 years (approximately 1 hour per data reporting).

7.PC shell, waterproof, dustproof and high temperature resistant.

Specifications

1.Battery parameters: 3.6V-8500mAh

2. Working current: shutdown <5uA, sleep: <10uA (average), working: <50ma (average)

3. Length of use: 5 years (reported once every hour) (the actual situation is calculated based on the upload time interval)

4. Shell volume: 100mm * 56mm * 44mm

5. Measuring range: acceleration: ±2 g, angle X Y90°,

6. Measuring inclination accuracy: 0.2°.

7. Caching: Up to 10,000 pieces of data can be cached when there is no Internet connection.

8. Data output content: acceleration, angle, battery voltage, XY alarm signal, upload interval, on-chip time, software version.
