    1. The module integrates high-precision gyroscopes, accelerometers, and geomagnetic field sensors, and uses high-performance microprocessors and advanced dynamics calculation and Kalman dynamic filtering algorithms to quickly solve the current real-time motion posture of the module.

    2. Using advanced digital filtering technology, it can effectively reduce measurement noise and improve measurement accuracy.

    3. An attitude solver is integrated inside the module, and combined with the dynamic Kalman filter algorithm, it can accurately output the current attitude of the module in a dynamic environment. The attitude measurement accuracy is 0.2°, the stability is extremely high, and the performance is even better than some professional inclination angles. instrument.

    4. The Z-axis heading angle is added to the geomagnetic sensor filter fusion, which solves the cumulative error caused by the drift of the gyroscope integral in the 6-axis algorithm, and can output heading angle data stably for a long time.


    Specifications

    Accelerometer parameters

    Parameters

    Condition

    Typical value

    Measuring range


    ±16g

    Resolution ratio

    ±16g

    0.0005(g/LSB)

    RMS noise

    Bandwidth=100Hz

    0.75~1mg-rms

    Static zero drift

    Place horizontally

    ±20~40mg

    Temperature drift

    -40°C ~ +85°C

    ±0.15mg/℃

    Bandwidth


    5~256Hz

    Gyroscope parameters

    Parameters

    Condition

    Typical value

    Measuring range


    ±2000°/s

    Resolution ratio

    ±2000°/s

    0.061(°/s)/(LSB)

    RMS noise

    Bandwidth=100Hz

    0.028~0.07(°/s)-rms

    Static zero drift

    Place horizontally

    ±0.5~1°/s

    Temperature drift

    -40°C ~ +85°C

    ±0.005~0.015 (°/s)/℃

    Bandwidth


    5~256Hz


    Magnetometer parameters

    parameters

    Condition

    Typical value

    Measuring range


    ±2Gauss

    Resolution ratio

    ±2Gauss

    0.0667mGauss/LSB

    Pitch and roll angle parameters

    parameters

    Condition

    Typical value

    Measuring range


    X:±180°

    Y:±90°

    Inclination accuracy


    0.2°

    Resolution ratio

    Place horizontally

    0.0055°

    Temperature drift

    -40°C ~ +85°C

    ±0.5~1°

    Note:

    【1】Please perform magnetic field calibration in the test environment before use to ensure that the sensor is familiar with the magnetic field in the environment. During calibration, please stay away from magnetic interference.

    【2】In some vibration environments, there will be cumulative errors. The specific errors cannot be estimated and will be subject to actual testing.


    Application

    · Virtual reality/augmented reality, head-mounted displays

    · Large-scale agricultural automatic farming

    · Safety monitoring of high-altitude operations

    · Drones, manned aircraft

    · Industrial attitude monitoring

    · Human motion tracking/capture

    · Robots, autonomous guided transport vehicles

    · Pedestrian navigation

    · Unmanned driving/assisted driving

    · Military, intelligent weapons and equipment



    Download

    Product Information

    Video
