  • JY-RM3100

    3-axis Geomagnetic Magnetometer IMU Sensor

    Overview

    • The module has its own voltage stabilization circuit, with an operating voltage of 3.3V~5V. The pin level is compatible with 3.3V/5V embedded systems and is easy to connect.

    • Supports three digital interfaces: serial port, SPI and IIC. SPI and IIC are directly connected to the chip, making it easy for users to choose the best development connection method.

    • Up to 100Hz data output rate. The output rate is adjustable from 0.1 to 100Hz.

    • The serial port can output the heading angle resolved by the magnetic field

    • 2-layer PCB board technology, thinner, smaller and more reliable.

    • Two modes: serial port mode and sensor direct connection mode.


    Specifications

    1. Voltage: 3.3V~5V

    2. Current: <6mA

    3. Volume: 15.24mm X 15.24mm X 7.8mm

    4. Pad spacing: 100mil (2.54mm) up and down, 600mil (15.24mm) left and right

    5. Data interface: serial port (TTL level, baud rate supports 9600 (default), 115200, 460800)

    6. Measuring range: -800uT~+800uT

    7. Sensitivity: 13nT/LSB

    8. Return transmission rate: adjustable from 0.1 to 100Hz.



    Application

              Compass                      Elevated Tower Crane                     Lift                              Solar Panels
